The Prototye Build creates the vehicle that brings the idea to life! This is where much fun, joy, satisfaction (and frustration) can be found. You order parts and assemble the circuit while anticipating how your abstract ideas will play out in the real world.
A prototype enables
Back to Design Series
Here's the schematic of our Digital Voltmeter showing the Solderless Breadboard and connections to the Arduino UNO Board.
There is no easier way to prototype a circuit than with the Solderless
Protoboards. Drop in a component and begin wiring! Although the breadboard
is limited to lower frequency designs, you can easily test, modify and
experiment with your design.
A handy online drawing program
(www.cirkitstudio.com/) allows you to create a parts-based wiring diagram as
shown below.
Please note, the diagram above is only a suggestion. Arrange parts and wire the circuit anyway you prefer!
Even with the most basic components, you can build a working digital voltmeter. The parts below were already preselected in the design strategy or calculated in the design phase. Feel free to select alternate components for preference / availability / cost.
The critical components to meet accuracy spec are the 0.1% resistors 200k and 806k.
Qty
(Ref)Description Part Number
(Digikey)1 Arduino Uno Rev3 Microcontroller Board A000066 1 pkg Adafruit Industries LLC JUMPER WIRE M TO M VARIOUS (1528-2185-ND) 1 SparkFun Electronics COM-00097 Push Button (1568-COM-00097-ND) 1 SparkFun Electronics PRT-12002 BREADBOARD (1568-PRT-12002-ND) 2 TEST LEADS GATOR TO GATOR, BLK, RED any available 2
(SW1,2)SSR RELAY SPST-NO 500MA 0-60V TLP592A(F)
(TLP592AF-ND)1
(R1)RES 806K OHM 0.1% 1/8W AXIAL any available 1
(R2)RES 200K OHM 0.1% 1/8W AXIAL any available 1
(RP1)RES 200K OHM 1% 1/8W AXIAL any available 1
(CP1)CAP CER 0.15UF 50V X7R RADIAL any available 2
(R3,4)RES 1K OHM 1% 1/8W AXIAL any available
Before you apply power!!! Perform a couple of simple tests to avoid potential damage to your circuit, Arduino or PC.
Grab a Digital Multimeter (cheap ones available < $10) and measure the resistance between the points listed below. Basically, a smaller resistance could draw excess power causing damage. Check the following with the POWER OFF (No USB or Power Cable connected to Arduino).
if PASS, then proceed
if FAIL, then recheck
wiring and component value, type, orientation.
The next step - apply the power and run the code!
Back to Design Series
